Full Metal Range TUB27 TUB32 TUB 38
TUB27, TUB32 and TUB 38 are specially designed for high air exhaust volume requirement in a ventilation system in premises with far distance from openings.
DESCRIPTION
Full Metal Range is specially designed for high air exhaust volume requirement in a ventilation system in premises with far distance from openings.
– Capacitor Run Induction Motor provides lower input power, high performance, long durability and stability
– Detachable cassette type discharge opening is designed for convenient ducting, installation and maintenance
– Various aesthetically pleasing design louvers for selection.
– Mounting feet are included for easy suspending and ceiling installation.
– Metal Sirocco Fan : well balanced, high graded aluminum high pressure centrifugal fan, quiet and stable operation.
– Welding joint design casing for durable and aesthetical need.
– Full metal construction for fire retardant requirement.
– 2-Speed control available for TUB32 and TUB38.
SPECIFICATION
| Model No. | Dimension (mm) | Applicable Duct Ø (mm) | Installation Space (mm) | Voltage | Input Power (W) | Sound Level (dB(A)) | Speed (R.P.M) | Air Volume (m³/min) | Air Pressure (Pa) |
|---|---|---|---|---|---|---|---|---|---|
| TUB27 | 307 x 258 x 330 | 150 | 270 x 270 | 220V~50Hz | 32 | 32 | 1040 | 4 | 100 |
| TUB32 | 360 x 260 x 390 | 150 | 320 x 320 | 220V~50Hz | High Speed: 45 Low Speed: 37 | High Speed: 42 Low Speed: 40 | High Speed: 690 Low Speed: 600 | High Speed: 6.8 Low Speed: 5.7 | High Speed: 160 Low Speed: 124 |
| TUB38 | 424 x 260 x 450 | 150 | 385 x 385 | 220V~50Hz | High Speed: 115 Low Speed: 95 | High Speed: 46 Low Speed: 44 | High Speed: 810 Low Speed: 650 | High Speed: 9 Low Speed: 7 | High Speed: 250 Low Speed: 192 |
